ROVER PRO
Intelligent, energy-efficient LED displays for demanding outdoor installations.
Standby low Power Consumption
When there is no input signal, the power supply cuts off the DC output. In this state, only the receiving card and the power supply itself consume energy, while the display modules remain completely unpowered.
Standby power consumption
lower


Dynamic Energy Saving
The standard DC voltage is kept as low as possible (e.g., 3.8V / 2.8V). The power supply continuously monitors the voltage at the farthest end and automatically adjusts the DC output in real time whenever it falls below the standard level.
Real-time voltage
monitoring & adjustment
Reduced power without
compromising uniformity
Lower heat generation
across the display
Optimized for large-
format configurations

Intelligent Module Monitoring System
The intelligent backend system enables real-time remote monitoring, detecting failures down to a single LED pixel for quick maintenance. It also continuously monitors voltage stability to prevent flickering, brightness inconsistency, and color deviation, ensuring reliable display performance.




Versatile Splicing Design
By customizing the cutting angle of the cabinet, it can support the splicing of various display forms, allowing the picture to cross boundaries and extend naturally, achieving multi-angle and multi-scene visual presentatio
Cutting Corners
Supports customized cutting angles from 1° to 45°.
Concave and convex
Support customized inner arc and inner angle installation.
Curved shape
Various curved cabinets can be customized according to needs to present a wonderful display.


15,000:1 Ultra-high contrast
The double-eyebrow design on the upper and lower lamp beads effectively reduces the interference of ambient light from the upper and lower directions and improves display clarity. The shutter structure design on the left and right sides reduces the impact of stray light incident from the sides and top. Innovative coating technology further reduces reflected glare while enhancing color performance, making black deeper and white purer, significantly improving overall contrast.

High Brightness, Low Power Consumption
It uses innovative through-hole SMD packaging technology to achieve a high brightness of 10,000nits, while power consumption is less than 300W, taking into account both excellent display effects and high efficiency energy saving performance.

Double-Sided Potting
Rover features Double-Sided Potting, with protective Potting applied to both the front and back of the product. This design enhances waterproof performance, making it more resistant to outdoor conditions such as rain, snow, and humidity, thereby improving reliability. Additionally, the Double-Sided Potting expands the heat effect area, ensuring moreuniform cooling and extending the product's lifespan.


Uneven heat effect

Low heat effect

Reliable outdoor performance with configuration-specific warranty
Rover Pro offers reliable outdoor LED performance with warranty coverage of up to 10 years, depending on the LED package and ordered configuration. Confirm the applicable warranty with RGBshine for your project.

Reliable performance. Warranty up to 10 years.
Excellent heat dissipation
performance
Extreme power consumption
performance
Multiple physical protection inside and outside
The Rover Pro series includes a 7-year warranty for SMD products and a 10-year warranty for through-hole SMD products. Confirm the applicable configuration and warranty terms with RGBshine before ordering.
Rover Pro Specifications
| Parameter group | Model | 4 | 5.714 | 6.67 | 10 | 13.33 | 16 |
|---|---|---|---|---|---|---|---|
| Physical Parameters | |||||||
| Physical Parameters | Cabinet Size (W x H x D) mm | 960x1280x72.5 / 960x960x72.5 / 960x640x72.5 | 960x1280x72.5 / 960x960x72.5 / 960x640x72.5 | 960x1280x72.5 / 960x960x72.5 / 960x640x72.5 | 960x1280x72.5 / 960x960x72.5 / 960x640x72.5 | 960x1280x72.5 / 960x960x72.5 / 960x640x72.5 | 960x1280x72.5 / 960x960x72.5 / 960x640x72.5 |
| Module size (W x H x D) mm | 480x320x20.3 | 480x320x20.3 | 480x320x20.3 | 480x320x20.3 | 480x320x20.3 | 480x320x20.3 | |
| Cabinet Resolution (WxH) pixels | 240x320 / 240x240 / 240x160 | 168x224 / 168x168 / 168x112 | 144x192 / 144x144 / 144x96 | 96x128 / 96x96 / 96x64 | 72x96 / 72x72 / 72x48 | 60x80 / 60x60 / 60x40 | |
| Full Display Weight (KG) | 36.5 / 30 / 22 | 36.5 / 30 / 22 | 36.5 / 30 / 22 | 36.5 / 30 / 22 | 36.5 / 30 / 22 | 36.5 / 30 / 22 | |
| IP G rade | IP65 | IP65 | IP65 | IP65 | IP65 | IP65 | |
| Optical Parameters | |||||||
| Optical Parameters | Brightness (nits = cd/m²) | ≤6,000 | ≤6,000 | ≤6,000 | ≤6,000 | ≤10,000 | ≤10,000 |
| Refresh Rate (Hz) | 7,680 | 7,680 | 7,680 | 7,680 | 7,680 | 7,680 | |
| Color Temperature (K) | 7,000±500 | 7,000±500 | 7,000±500 | 7,000±500 | 7,000±500 | 7,000±500 | |
| Contrast | 15,000:1 | 15,000:1 | 15,000:1 | 15,000:1 | 15,000:1 | 15,000:1 | |
| Viewing Angle | H: 130°/V: 110° | H: 130°/V: 110° | H: 130°/V: 110° | H: 130°/V: 110° | H: 130°/V: 110° | H: 130°/V: 110° | |
| Electrical Parameters | |||||||
| Electrical Parameters | Power Consumption Max (W/m²) | ≤589 | ≤534 | ≤534 | ≤534 | ≤330 | ≤330 |
| Power Consumption Typical (W/m²) | ≤196 | ≤178 | ≤178 | ≤178 | ≤104 | ≤104 | |
| Working Voltage | 100V~240V / 50-60Hz | 100V~240V / 50-60Hz | 100V~240V / 50-60Hz | 100V~240V / 50-60Hz | 100V~240V / 50-60Hz | 100V~240V / 50-60Hz | |
Specifications depend on the selected configuration. Final specifications are subject to the sales quotation.
